We Offer a Wide Range of Technical Drawing Supplies & Drafting Equipment.

A Large Number of Our Products Are Imported or Distributed Exclusively by Draftex Allowing us to Offer Quality Specialist Products, Which Represent Excellent Value For Money.

1522 A2 Drafting Unit

Board 700 x 550mm F50 Adjustable Backstand Draftex Parallel Rule $280

1302 A2 Drafting Unit

Board 700 x 550mm F50 Adjustable Backstand $158.75

1422 A2 Drafting Unit

Board 700 x 550mm Carry Handle / Tilt Stand Draftex Parallel Rule $235.50

1101 Tee Square

Wooden Stock and Blade with White Plastic Drawing Edge. Edge is Raised from the Board Surface to avoid Smudging of Ink Work.Traditional Tapered Blade. Available in 60cm, 90cm and 105cm.

1102 Tee Square

Wooden Stock and Blade with Clear Plastic Edges. Edges are Raised from the Board Surface to avoid Smudging of Ink Work. Parallel Blade for Left or Right Handed Use. Available in 60cm 90cm and 105cm.

1106 Tee Square

Plastic Headstock and Clear Acrylic Blade with Inking Edge, Removable Headstock with Carry Pouch for Portability, Left or Right Handed Use. Available in 60cm, 90cm and 105cm.

Replacement Wires for Parallel Rules

Replacement Wires for Parallel Motion Rules Plastic Coated Wire with 60 Pound Breaking Strain and Tension Spring Custom Sized for Each Parallel Rule Length

Draftex Parallel Rules

Draftex Parallel Rules. Locking Feature Frees Hands for Drawing. Guided by Wires Attached to the Edge of the Drawing Board. Very Accurate Results Available to Suit A1 up to A0 Drawings.

Melamine Drawing Boards

Drawing Boards in Sizes to Suit our Drafting Machines and Parallel Rules.

DS30

Drafting Stand for Drawing Boards up to 1500 x 1000mm with Positive Pin Lock Height Adjustment and Lever Angle Adjustment.

Drawing Board Support

Steel Drawing Board Board Support / Backstand for Desktop or Table Use. Includes 5 Different Adjustable Angles and Rubber Feet for Anti-Slip.

Draftex Plan Clamps

Strong Economical Plan Hanging Clamps 3 Sizes Available - To suit Draftex Trolleys & Wallracks Anodised Aluminium Available Individually or Box of 10 10 Year Warranty - Best Value for Money

Draftex Plan Trolleys

Draftex Front Loading Plan Trolleys Strong and Stable Steel Construction Available in 4 Size / Capacity Options Best Value for Your Dollar

Draftex Wall Rack

Wall Mounted Plan Rack - Sturdy Pressed Steel Contruction 10 Plan Clamp Capacity - Store up to 1000 drawings Clamps are side loaded - (Load Clamps either side)

Telescopic Plan Tube 2400

630 - 980mm Telescopic Plan Tube with Shoulder Carry Strap

Cardboard Plan Tube

Cardboard Tubes for Archival or Postal Usage with Plastic End Caps

Bond 80gsm 150m Rolls

Chromajet Reflex Bond Paper for Plan Printing Machines. High White and Low Dust for Optimal Print Quality. Produced from Plantation Grown Timber

Draftex Clutch Pencil 2mm

5230 Traditional Blue Barrel and Chrome With Metal Grip, Pocket Clip, Lead Pointer and Lead Indicator.

3mm White Foam Core

Foam Core Board in 3mm Thickness. High Density Polystyrene Fill Board with High Quality Clay-Coated Matte Paper Liner on both sides available.Available in 4 sizes

5mm White Self Adhesive Foam Core

White Polystyrene Board with Permanent Acrylic based High-Tack adhesive surface on 1 side with silicon release liner. Available in 3 sizes

5mm Black Foam Core

Black Foam Core Board in 5mm Thickness. High Density Polystyrene Fill Board with High Quality Clay-Coated Matte Paper Liner on both sides also available in 6 sizes

10mm White Foam Core

High Density Polystyrene Fill Foam Core Board with a quality Clay Coated Matte Paper Liner on both sides. Easy to work with & cuts effortlessly - very smooth PH Neutral Surface

DC737 Quickbow Compass Set

Quickbow Compass is a Masterbow Compass with Rapid Lever Adjustment for Circles up to 300mm. The head is Geared for Precision. This Model is Auto Locking with Metallic Finish. Includes Extension Bar w

DC833 Quickbow Technical Compass Set

Quickbow is a Masterbow with Rapid Adjust Compass for Circles up to 350mm. This Compass has an Integrated Technical Pen and Mechanical Pencil Fitting. Includes Extension Bar which extends Diameter to

DC621 Basic Compass Set

6 Piece Basic Drawing Compass Set containing Geared Friction Head Compass for Circles up to 220mm, Extension Bar, Small Springbow Compass with Pen/Ink Attachment, Ruling Pen and Lead Tube with Replace

DC1246 Masterbow Compass Set

Masterbow / Springbow Compass Set for Circles up to 210mm Diameter. Includes Extension Bar which extends diameter to 450mm, Pen Adaptor and Lead Tube with Replacement Leads.

DC1247 Masterbow Compass Divider Set

Masterbow / Springbow Compass Divider Set for Circles up to 210mm Diameter. Includes Extension Bar which extends diameter to 450mm, Dividers, Pen Adaptor and Lead Tube with Replacement Leads.

DC836 Dropbow Compass

All Metal Drop Compass for Very Small Circles up to 29mm Diameter.

Beam Compasses

Beam Compass set (also known as Trammels) comprising: 2 x 30cm Alloy Beams for circles up to 1200mm Diameter. .5 Pencil, Joining Block, Technical Pen Attachment, Ruling Pen, Compass Point and 2mm Lea

Technical Pen Adaptor

Threaded Technical Pen Adaptor for Compasses. Suits FL25 Mechanical Finelead Pencil and other Standard Technical Pens

Universal Compass Adaptor

Screw Clamp Universal Adaptor Compass Attachment for Pens and Markers of Varying Widths.

2mm Compass Leads

Tube of Leads in 2mm Width for Compasses. Available in Tube of 2 or 6.

Finelead Compass Pencil

0.5mm Mechanical Pencil Compass Attachment with Threaded Connection for Attaching to CA35 Pen Adaptor

Cutting Blade

Sharp Steel Blade Inserts into Compass in Place of Lead for Cutting Circles in Paper and Light Card

Proportional Dividers

19cm Duraluminum Proportional Divider 190mm. Graduated for Lines & Circles Adjustable Steel Points.

Ruling Pen

Ruling Pen for Creating Lines in Ink, Paint or Similar Media. Line Width is Adjustable with Thumbscrew.

Draftex Adjustable Set Squares

Acrylic Adjustable Set Square with Bevelled and Inking Edge, Also Known as an Adjustable Trigonometric Triangle, Measurements in Degrees, Slope and Rise, Clear Square with White Quadrant, Magnified C

5mm White Foam Core

High Density Polystyrene Fill Board with High Quality Clay-Coated Matte Paper Liner on both sides available in A1, A2, A3, A4, 32 x 40"and 40x60"

Draftex Set Square Sets

Draftex Set Square Sets 1 x 45° and 1 x 60°/30°. Graduations Start at Corner and Extend to End, Slight Bevel to Graduated Edge, May Be Inverted for Ruling With Markers or Ink, Tough Acrylic Material.

Rolling Ruler

Acrylic Mould, Includes Mini Protractor at Centre, Increments in Inches and Centimetres, Suitable for Drawing Parallel Lines, Circles, Angles and other Geometrical Shapes.

Draftex Fineline Mechanical Pencils

Fineline Mechanical Lead Pencils in 0.5 and 0.7mm. Available in Plastic Barrel and All Metal Options.

Telescopic Plan Tube 2500

720 - 1240mm Telescopic Plan Tube with Shoulder Carry Strap

Tecnostyl Drafting Machine 628B

Track Drafting Machine to Suit 800 x 1200 Size Drawing Board. Complete with 300mm and 400mm Scale Rules.

Plan Trimmers

Plan Trimmer With Stand and Paper Catcher. Available in One Size A1 OVERSTOCKED AND NEED TO SELL. GRAB A REAL BARGAIN. ON SALE NOW $95

Drafting Chair

Gas Lift Drafting Chair with Five Star Base. Backrest Adjusts for Lumbar Support. Seat Base has Tilt Function. Durable Fabric Covering.

Lead Pointers

Lead Pointers for Sharpening 2mm Leads Used with Clutch Pencils. Available in a Rotating Barrel or Plain Sharpener.

Erasing Shield

Erasing Shield in Stainless Steel Allows Accurate Erasure While Protecting Other Work

Dusting Brush

Dusting Brush For Cleaning Drawing and Board Surfaces.

Flexible Curves

Flexible Curves Can be Bent to Form the Desired Shape, Adjusts Quickly from One Shape to Another, One Edge has Raised Strip for Drawing with Ink. Available in Five Lengths 30cm, 40cm, 50cm, 60cm and 9

Cutting Mats

Green Cutting Mats. Self Healing Surface. Four Sizes Available

Steel Rules

Stainless Steel Rulers with Metric Graduations. Available in 15cm, 30cm, 45cm, 60cm, and 100cm Lengths

French Curves

French Curves in Set of Three, Supplied in Clear Plastic Wallet, Inking Edges Prevent Smudging when using Pens or Markers.

Tracing Paper Pads

Quality Tracing Paper 110gsm in Pads of 50 Sheets. Heavy Board Backing.

53gsm Detail Paper Pads

53gsm Gateway Brand Detail Paper in a Pad of 100 Sheets.

Butter Paper 27gsm

Butter Paper for Sketch Work. Lightweight, Translucent and Economical.

Draftex Scale Rulers

Draftex Oval Section Scales Conform to AS1212 Standards. Two Different Scale Sets Available in Either 15cm and 30cm.

Draftex Triangular Scale Rules

Draftex Triangular Scales in ABS Plastic, Colour Coded Centre Strip, Hard Plastic Carry Case. Range of 4 Available; TSR1, TSR2, TSR3, TSR4.

1521 A1 Drafting Unit

Board 900 x 720mm F50 Adjustable Backstand Draftex Parallel Rule $307

1301 A1 Drafting Unit

Board 900 x 720mm F50 Adjustable Backstand $192.30

1421 A1 Drafting Unit

Board 900 x 720mm Carry Handle / Tilt Stand Draftex Parallel Rule $271.45

1201 A1 Drafting Unit

Board 900 x 720mm Carry Handle / Tilt Stand $140.75

1202 A2 Drafting Unit

Board 700 x 550mm Carry Handle / Tilt Stand $101.70

DC240 Springbow Compass

Springbow Compass Set for Circles up to 125mm Diameter. Includes Lead Tube with Replacement Leads.

PFP1 A1 Trolley plus 5 Clamps

1 x A1 10 Clamp Capacity Trolley 5 x A1 Clamps All for $308.09 plus GST.

PFP2 A1 Plan Trolley plus 10 Clamps

1 x A1 10 Clamp Capacity Trolley 10 x A1 Clamps All for $415.09 plus GST.

PFP3 A1 Plan Trolley plus 10 Clamps

1 x A1 20 Clamp Capacity Trolley 10 x A1 Clamps All for $421.36 plus GST.

PFP4 A1 Plan Trolley plus 20 Clamps

1 x A1 20 Clamp Capacity Trolley 20 x A1 Clamps All for $671 plus GST

PFP5 B1 Plan Trolley plus 10 Clamps

1 x A0 10 Clamp Capacity Trolley 10 x B1 Clamps All for $453.64 plus GST

PFP6 B1 Plan Trolley plus 20 Clamps

1 x A0 20 Clamp Capacity Trolley 20 x B1 Clamps All for $711.45 plus GST

PFP7 A0 Plan Trolley plus 5 Clamps

1 x A0 10 Clamp Capacity Trolley 5 x A0 Clamps All for $342 plus GST

PFP8 A0 Plan Trolley plus 10 Clamps

1 x A0 10 Clamp Capacity Trolley 10 x A0 Clamps All for $468 plus GST

PFP9 A0 Plan Trolley plus 10 Clamps

1 x A0 20 Clamp Capacity Trolley 10 x A0 Clamps All for $474.82 plus GST

PFP10 A0 Plan Trolley plus 20 Clamps

1 x A0 20 Clamp Capacity Trolley 20 x A0 Clamps All for $733.55 plus GST

Plan Reading Table PRTA1

Board an Stand Package for Viewing Plans up to A1 Size. Includes Instrument Tray, Page Cips and Lip on Bottom Edge. Stand is Tilt Adjustable.

Plan Reading Table PRTA0

Board an Stand Package for Viewing Plans up to A0 Size. Includes Instrument Tray, Page Clips and Lip on Bottom Edge. Stand is Height and Tilt Adjustable.

DEP21A0 Drafting Package

Board 1370 x 900mm DS30 Drafting Stand Draftex Parallel Rule $804.

DEP13A1 Drafting Package

Board 1050 x 750mm DS20 Drafting Stand Draftex Parallel Rule

DEP16B1 Drafting Package

Board 1200 x 800mm F50 Backstand Draftex Parallel Rule $416.

DEP19B1 Drafting Package

Board 1200 x 800mm DS20 Drafting Stand Draftex Parallel Rule $594.

DEP9A1 Drafting Unit

Board 1050 x 750mm F50 Adjustable Backstand Draftex Parallel Rule $379.

Paper Pack

Paper Pack

Coloured Pencil Set

Faber Castell Coloured Pencil Set of 26 for Ryde Tafe - Prepare A Landscape Project Design

Clutch Pencil with Leads

Draftex Clutch Pencil to Suit 2mm Leads. Chrome Grip, Pocket Clip and Unique Lead Indicator 5230L1: Clutch Pencil with 2 x 2H Leads 5230L: Clutch Pencil with 2 x HB & 2 x 2H Leads 5230BL: Clutch Penci

Draftex A3 Drawing Board

Draftex Matix A3 Drawing Board with Double Locking Parallel Rule and Set Square Protractor. Also available with Carry Bag with Shoulder strap.

Protractors

150mm Diameter Protractors. Available in 180° and 360°.

Foamboard Hanger

Foamboard Screw type Plastic Hangers are ideal for suspending or Hanging Foam Core Boards from the top. Use 2 hangers to suspend sign from ceiling.

Modelling Starter Pack for ARCH1142

Modelling Starter Pk: containing 2 Each of 1mm + 1 Each of 1.5 & 1.8mm A2 Boxboard Sheets

KnifeGuard

KnifeGuard is a magnetic device designed to protect your fingers and to make cutting safer when using a Sharp Knife or Scalpel and a Steel Rule

Drafting Machine Package DEP22A1

Tecnostyl Drafting Machine DS30 Drafting Stand 1200 x 800mm Drawing Board

DS20

Drafting Stand with Height and Angle Adjustment for Drawing Boards up to 1300 x 900mm.

Bank Pad A3

Bank Pad A3

Aluminium Safety Cutting Rule

Aluminium Safety Cutting Rule. Available in 30cm, 45cm or 60cm Lengths. Flip Up or Fold Down Finger Guard. Non-slip, Ribbed Rubber Grip.

Ames Lettering Guide

Ames Lettering Guide AL666 for Laying out Guidelines for Hand Lettering.

1202U A2 Drafting Unit

UNSW - Board 700 x 550mm Carry Handle / Tilt Stand

Pre Printed Tracing Paper

Tracing Paper 112gsm with Pre-Printed Title Block and Border Available in A1, A2, A3 & A4 Sizes
