Budget General Templates Starting from $12.95

  • 1871 Isomars Combination Circle Sqaure Triangles And Ellipse Drawing Template
  • 6039 Isomars Combination Circle Sqaure Triangles And Ellipse Drawing Template
  • 1831 Isomars 2Mm To50mm 45 Degree Ellipse Drawing Template
  • 1833 Isomars 2Mm To 60Mm Isometric Ellipse Drawing Template
  • 1834 Isomars Multi Ellipse Drawing Template In 25 35 45 And 60 Degree Projections
  • 1838 Isomars Multi Ellipse Drawing Template In 20 30 40 And 50 Degree Projections
  • 1811 Isomars Combination Drawing Template
1871
Quantity

Isomars General Templates are made from 1.8mm acrylic in light orange hue. Range includes drawing for ellipses, circles, squares, triangles, hexagons and metric bolt heads.

  • 1871 Combination - Circles, Squares, Triangles and Ellipses in a Range of Sizes.
  • 6039 Combination - Circles, Squares, Triangles and Hexagons with Metric Bolt Heads from M2 to M8.
  • 1831 Ellipse - 26 x 45 Degree Ellipses from 2 to 50mm Long Axis.
  • 1833 Isometric Ellipse - 35 Degree 16 Minute Projection. 27 Ellipses from 2 to 60mm on the Isometric Axis.
  • 1834 Multi Ellipse - Over 60 Ellipses in 25, 35,45 and 60 Degree Projections.
  • 1838 Multi Ellipse - Over 60 Ellipses in 20, 30,40 and 50 Degree Projections.
  • 1811 Combination - Rectangles, Triangles and Ellipses in a Range of Sizes.

1871 Combination Template with Circles, Squares, Triangles and Ellipses in a range of sizes. Made from 1.8mm Acrylic in Light Orange Hue.

6039 Combination Template showing Circles , Squares, Triangles and Hexagons with Metric Bolt Heads from M2 to M8. Made from 1.8mm Acrylic in Light Orange Hue.

1831 Ellipse Template with 26 x 45 degree Ellipses from 2 to 50mm long axis. Made from 1.8mm Acrylic in Light Orange Hue. Ellipses are marked with long and short axis lines to assist with locating on the drawing.

1833 Isometric Ellipse Template. 35 Degree 16 Minute Projection. 27 Ellipses from 2 to 60mm on the isometric axis. Made from 1.8mm acrylic in light orange hue.

1834 Multi Ellipse Template with over 60 Ellipses in 25, 35,45 and 60 degree projections. . Ellipses are marked with long and short axis lines to assist with locating on the drawing. Made from 1.8mm Acrylic in Light Orange Hue.

1838 Multi Ellipse Template with over 60 Ellipses in 20, 30,40 and 50 degree projections. . Ellipses are marked with long and short axis lines to assist with locating on the drawing. Made from 1.8mm Acrylic in Light Orange Hue.

1811 Combination Template showing Rectangles, Triangles and Ellipses in a Range of Sizes. Made from 1.8mm Acrylic in Light Orange Hue.

Code Unit Description Dimensions Weight
1871EachIsomars Combo Circle, Square Tri & Ellip243L x 120W x 2H40 (g)
6039EachIsomars Combo Circle, Square Tri & Ellip155L x 85W x 2H20 (g)
1831EachIsomars 2-50mm 45° Ellipse Template180L x 10W x 2H20 (g)
1833EachIsomars 2-60mm Isometric Ellipse Templat295L x 145W x 2H40 (g)
1834EachIsomars Multi Ellipse 25,35,45,60 Degree280L x 140W x 2H40 (g)
1838EachIsomars Multi Ellipse 20,30,40,50 Degree263L x 128W x 2H40 (g)
1811EachIsomars Combo Rectangles, Tri & Ellipse260L x 126W x 2H40 (g)
